tsis muaj Rails Dual Camera Me SMT PCB Los Ua Ke Tshuab
SMT PCB Los Ua Ke Tshuab Taw Qhia
SMT PCB Los Ua Ke Tshuab NeoDen4 yog xaiv thiab tso lub tshuab ntawm cov khoom hloov pauv, PCB hloov pauv thiab hloov pauv tau yooj yim. Nws tau nruab nrog ob lub koob yees duab CCD, pib tsheb, pib siv hluav taws xob thiab 4 lub taub hau tso, uas tuaj yeem txhawb nqa 0201, BGA, QFN.
SMT PCB Los Ua Ke Tshuab yog qhov kev xaiv zoo tshaj plaws kom txaus siab rau txhua qhov xav tau ntawm qhov ua tau zoo, muaj peev xwm siab, ua haujlwm ruaj khov thiab raug nqi tsawg. Qhov no yog qhov kev ua tiav loj tsis yog rau NeoDen nkaus xwb, tab sis kuj rau cov lag luam me thiab nruab nrab, cov uas xav txhim kho kev tso chaw raug thiab ua kom nrawm PCB sib dhos nrog cov peev txheej tsawg.
Kev qhia tshwj xeeb
Qauv | tsis muaj Rails Dual Camera Me SMT PCB Sib dhos Tshuab NeoDen4 |
Tshuab style | Tib leeg nrog 4 lub taub hau |
Tuab si lug | Theem Zeem Muag |
Tus Nqi Tso Npe | Lub zeem muag ntawm: 5,000CPH |
Lub zeem muag tawm: 10,000CPH (Optimum) | |
Peev Xwm Feeder | Daim kab xev pub mis: 48 (tag nrho 8mm) |
Kev co kev co: 5 | |
Tais feeder: 5 | |
Cheeb Tsam Ntau Yam | Qhov Loj Me Me: 0201 |
Loj Tshaj Loj | 32x32mm (Lead Suab 0.5mm) |
Max Siab | 5 hli |
Kev sib hloov | ±180° |
Kev Raug Rho Npe | ± 0.02 hli |
XY Rov Ua Dua | ± 0.02 hli |
Rooj Tswjhwm Saib Dimension (hli) | Qhov siab tshaj plaws: 350 x 400mm |
| 140x400mm (Nrog 1 waffle Tais) | |
Main Tswj | GUI |
Khoom Siv Hluav Taws Xob | 110V/220V |
Fais fab | 180W |
Sab Nraud Sab Nraud (hli) | Tshuab loj: 870 (L) x680 (W) x480 (H) |
Ntim loj | Ntim loj: 940 (L) x740 (W) x600 (H) |
Qhov hnyav | Net Nyhav: 60kgs |
Qhov hnyav tag nrho: 80kgs |
Nta
Dual-Vision system
Lub koob yees duab zoo saib thiab lub ntsej muag saib lub ntsej muag txheeb xyuas thiab ntsuas cov khoom sib txawv ib txhij, uas zoo kawg li txhim kho qhov tseeb ntawm kev tso chaw los ntawm 0201 rau BGA
Plaub lub taub hau tseeb
Plaub qhov kev tso siab rau lub taub hau nrog ± 180 ° kev sib hloov uas tau txais kev tshem tawm, ua kom sib luag thiab qib siab ntawm txoj kev sib txuas, kom ntseeg tau tias nws tuaj yeem txhim kho cov khoom nrog qhov chaw siab dua, ntau dua thiab raug
Ntse Feeders
Txais yuav cov txheej txheem kho qhov yuam kev los pab ua kom du thiab txo qhov sib txawv
Auto Rails Ua tiav Kev Tso Mus Ntxiv
1.5m tsheb ciav hlau tuaj yeem txuas nrog cov thauj khoom thoob ntiaj teb kom ua tiav qhov kev tso kawm tas mus li
Kev thauj khoom dav dav tau txhawb nqa
Nrog lub chaw thauj khoom, Ib-Ntej SMT cov kab tsim khoom tuaj yeem teeb tsa, uas yog lub sijhawm txuag thiab txuag zog ntau dua
Txhawb kev hloov kho tej thaj chaw deb
NeoDen yuav muab kev pab cuam lub neej ntev thiab kev txhim kho cov txheej txheem
Muaj PC motherboard
32G lub xeev muaj zog tsav, nyeem/sau tau nrawm dua thiab ruaj khov, nrog rau kev ua haujlwm tiv thaiv hluav taws xob
Daim ntawv teev cov khoom siv ntxiv
1) Xaiv thiab Muab Tshuab NeoDen4: 1
2) Nozzle qty: 6
3) 8G Flash Drive: 1
4) Qaum Fais Fab (5M): 1
5) Kev cob qhia video: 1
6) Daim Kab Xev Ob Sab: 2
7) Allen ciaj ntswj teeb: 5
8) Tool Box: 1
9) Cov tuav tuav tuav: 1
10) Kev co Feeder: 1
11) Cov Khoom Rail: 4
12) Neeg siv phau ntawv: 1
Cov nyhuv tso kawm
Muaj ntau hom lus
NeoDen's Kev Txhawb Ntau Yam Lus tso cai rau koj siv sib txawv, txhais cov ntawv ntawm koj li software rau 5 yam lus sib txawv, Lus Askiv, Kauslim, Lavxias, Suav, Suav, Portuguese.
Ntau hom lus yuav muaj sai sai no, nyob twj ywm.
Warranty
Lub sijhawm lav yog 2 xyoos txij li lub sijhawm yuav khoom thiab kev pab cuam mus tas ib txhis nrog rau lub sijhawm ua haujlwm tau zoo ntawm lub Hoobkas. NeoDen yuav muab Q/A online thiab daws teeb meem kev txhawb nqa thiab kev qhia tswv yim kev pabcuam.
Txog Peb
R& D pab neeg:6 tus kws tshaj lij software, 11 tus kws tsim khoom kho vajtse, 7 tus kws tsim khoom siv hluav taws xob, 4 tus kws tshuaj ntsuam xyuas kom paub tseeb tias peb tuaj yeem tsim tus qauv tshiab hauv txhua 1 ~ 2 xyoos
Pab pawg tsim khoom:115 tus neeg ua haujlwm tau ua haujlwm nyob rau hauv cov txheej txheem los ntawm kev kho vajtse txiav, sib dhos, ntsuas kom tiav cov khoom hauv khw muag khoom. 100% xeem los ntawm txhua qhov khoom siv ntxiv rau tshuab ua kom tiav kom zoo.
Pab neeg muag:35 kev tshaj lij muag rau kev lag luam hauv tsev thiab 10 rau kev ua lag luam txawv teb chaws, NEODEN kev lag luam sib faib nce xyoo ib xyoos nrog kev siv zog ntawm peb pab pawg
Pab neeg muag khoom tom qab:11 cov kws tsim khoom tom qab muag, ua lub zog txhawb nqa rov qab los pab cov neeg siv khoom hauv kev saib xyuas thiab kev txhawb nqa, nyob rau tib lub sijhawm sau cov ntaub ntawv thawj zaug los ntawm cov neeg siv khoom los tawm tswv yim R& D kom NEODEN cov tshuab siv tau rau ib txwm hloov pauv kev ua lag luam
Yog tias koj xav tau, thov hu rau peb kom paub ntau ntxiv.
