Me SMT Xaiv thiab Qhov Chaw Tshuab rau Tus Qauv
NeoDen4 Taw qhia
NeoDen4 yog SMT me me tuaj tos thiab tso tshuab rau cov qauv ntawm cov khoom yooj yim, PCB yooj thiab ntau lawm yooj yim.
Nws yog txawm peem rau nrog ob lub koob yees duab CCD, nws pib rails, nws pib hluav taws xob feeders thiab 4 lub taub hau tso, uas yuav pab tau rau mount 0201, BGA, QFN. Tshwj xeeb, nrog nws Internal rails, nws muaj feem xyuam rau 0.8m / 1.2m / 1.5m LED sawb.
Specification
| Khoom npe | NeoDen 4me SMT tuaj tos thiab tso tshuab rau tus qauv | Feeders | 48 pcs |
| Tshuab Style | Ib leeg Gantry nrog 4 Lub taub hau | Nruab nrab lub zog ua haujlwm | 220V/160W |
| Qhov chaw tso kawm | 4000 CPH | Component Range | Yam tsawg kawg nkaus: 0201 |
| Sab nraud Dimension | Loj: L 680 * W 870 * H 460mm | Loj: TQFP240 | |
| Max siv tau PCB | 290mm * 1200 hli | Max Qhov siab: 5mm |
Sample Boards los ntawm ob peb cov neeg siv khoom
Vim li cas thiaj xaiv NeoDen
Muab One Stop SMT Solution
NeoDen tsis tsuas yog tshwj xeeb hauv Me Smt Pick Thiab Qhov Chaw Tshuab, tab sis kuj tseem siv cov tshuab luam ntawv, cov tshuab luam ntawv thiab cov khoom siv, uas tuaj yeem muab cov neeg siv khoom ib qho kev daws teeb meem SMT.
Yooj yim rau kev khiav lag luam
Nrog built-in PC, koj tsuas yog xav tau lub monitor & keyboard los tswj lub tshuab.
Thaum koj tsim cov ntaub ntawv sib koom tes los ntawm PCB tsim software (AD, Eagle, KiCad, Upverter, thiab lwm yam), nws tsuas yog siv sijhawm 5-15 mins rau qhov program.
Ntiaj Teb Kev Muag Khoom Network
NeoDen muaj ntau tshaj 15 tus neeg muag khoom thoob ntiaj teb, piv txwv li, Is Nrias teb, Netherlands, Russia, Tebchaws USA, Nyiv, Kaus Lim Qab Teb, Qaib ntxhw, Brazil, Colombia, Nyab Laj.Iran, Australia, Chile, Argentina thiab Taiwan.
Txhua tus neeg xa khoom tuaj yeem muab kev tshaj lij ua ntej muag, kev cob qhia thiab kev txhawb nqa rau cov neeg siv khoom hauv zos.
Kev Them Nyiaj thiab Kev Xa Khoom
1) Kev Them Nyiaj: PayPal, West Union, Credit Card, thiab lwm yam
2) Txoj kev xa khoom ua ntej yog los ntawm TNT (qhov rooj rau qhov rooj), tshwj tsis yog qhov yuav tsum tau muaj los ntawm cov neeg siv khoom.
3) Lub sij hawm xa tuaj: 2-3 hnub ua haujlwm.
Warranty
Lub sij hawm lav rau NeoDen4 Me Smt Pick Thiab Qhov Chaw Tshuab (Rau Tus Qauv) yog 2 xyoos txij li lub sijhawm yuav khoom thiab kev pab txhawb nqa lub neej nrog rau lub Hoobkas mus sij hawm ntev.
NeoDen yuav muab Q/A online thiab pab daws teeb meem thiab kev pab tswv yim.
Txog Peb
Yog tias koj xav tau, thov hu rau peb kom paub ntau ntxiv.
